Description
- Customized number of detectors up to 10 detectors for gamma detection. 6 detectors as the standard solution.
- Customized detector size for each customer and application: 50×50 cm, 30×30 cm, etc.
- The detectors can be designed to be also sensitive to beta radiation becoming a beta/gamma monitor
- Typical efficiency per detector >20% (Cl-36), >9% (Tc99), >30% (Co-60 gamma)
- 220 VAC, 60 Hz or 110 VAC 50 Hz
- 1 10” touch screen for information and equipment control
- Automatic dynamic measurement time calculation
- Sensors for person detection
- Automatic barrier system
- Automatic adjustable head detector
- Audible and visual alarms
- User can customize the number of doors (0, 1 or 2)
- Chamber volume can be customized to fit small objects up to drums and big bags
- Up to 10 cm of lead shielding (adjustable).
- Automatic registration of all event, backgrounds, measurements, alarms, operation failures, etc.
- Digital adjustment of the detectors (no any mechanical intervention is required)
- Industrial PC with the latest OS Windows version
- Calibration, verification and configuration modules
- Software HS-RAD, that can be customized in any language
- Voice module for customized voice messages
- Remote operation can be included (TCP/IP)
- USB connection for downloading all the data to an external device
- Detection Limit calculation according to ISO 11929
