Description
|
SR555 Specifications |
|
| General | |
| Gain | 107 V/A |
| Bandwidth | 120 kHz (-3 dB) |
| Input noise (typ.) | 42 fA/√Hz at 1 kHz |
| Current input | |
| Impedance | 50 Ω |
| Bias current | <3 pA |
| DC bias input | |
| Range | ±5 VDC |
| Settling time | <150 ms |
| Impedance | 1 MΩ |
| Gain accuracy | 1 % |
| Gain stability | ±50 ppm/°C |
| Output | 20 Vpp max. balanced differential 10 mA max., 50 Ω |
| Power | Supplied by SR510, SR530, SR810, SR830 or SR850 or SR124 via connector cable |
| Dimensions | 3.0″ × 1.3″ × 5.1″ (WHL) |
| Weight | 10 oz. |
| Warranty | One year parts and labor on defects in materials and workmanship |
