Description
1. 20 mm construction rail
| Model No | Length (mm) | Mounting | |
| BX-20RL-210 | 210 |
M4 tapped holes |
|
| BX-20RL-260 | 260 | ||
| BX-20RL-310 | 310 | ||
| BX-20RL-360 | 360 | ||
| BX-20RL-410 | 410 | ||
| BX-20RL-460 | 460 | ||
| BX-20RL-510 | 510 | ||
| BX-20RL-560 | 560 | ||
| BX-20RL-710 | 710 | ||
| BX-20RL-860 | 860 | ||
| BX-20RL-960 | 960 | ||
| BX-20RL-1200 | 1200 | ||
| BX-20RL-XXX | Custom length * |
* Maximum length upto – 1800 mm only
2. Corner Cube
| Model No | Size (mm) | Mounting | |
| BX-20-CC | 20 x 20 x 20 | M4 CBR |
3. Hinges
| Model No | |
| BX-20-HG |
4. Magnetic latch with holder
| Model No | |
| BX-20-MGH |
5. Handles
| Model No | Type | |
| BX-20-SSU | Stainless steel U shaped handle along with mounting plate screws and T nut | |
| BX-20-PH4 | Plastic handle (4 inch) with insert screws and T nut |
6. Cover Sheets
| Model No | L x W (mm) | Type | |
| BX-20-3TAS-A-B | A x B | 3 mm thick transparent acrylic sheet (custom size *) | |
| BX-20-3BAS-A-B | A x B | 3 mm thick black acrylic sheet (custom size *) |
Method to specify A and B
‘A’ side rail length + 10 mm
‘B’ side rail length + 10 mm
Eg: ‘A’ side rail length = 360 mm, then L = 370 mm
‘B’ side rail length = 510 mm, then W = 520 mm
7. Rubber beading
Rubber beading is used for tightening the panels inside aluminium frame.
| Model No | Size | |
| BX-20-RB | 5 meters |
8. Clamps
| Model No | Type | |
| BX-20-TB | Table clamp for fixing to breadboard |
9. T-nut and Screws
| Model No | Type | Qty | |
| BX-20-TN | T – nut | 50 per pack | |
| BX-20-M4-10 | M4 x 10 screw | 50 per pack | |
| BX-20-M3-10 | M3 x 10 screw | 50 per pack | |
| Allen key | Allen key set | 1 set | |
| Spring washer | Spring washer | 50 per pack |
